Wall Mounted Dosing System with AC Adapter

The Hydro Systems 1190 AutoDose is a programmable automated dosing system that requires little day-to-day effort and eliminates human error in dosing amounts. Wall mount, compact size and AC power makes it easy to install where it is needed most, and you can essentially plug it in and forget about it! As long as there are chemicals and power, the unit will operate on your programming schedule with no day-to-day interaction. Perfect for drain cleaning, cooling towers, boilers, lubrication systems, pools, and other areas that need regular frequent dosing of maintenance chemicals to keep them clean. This version of the Hydro Systems AutoDose is designed to be mounted on a wall or flat surface.

Dimensions: 4 3/4" X 6 3/4" X 8 1/3"

Specifications:

• 12V AC power required -adapter included - USE ONLY THE SUPPLIED ADAPTER FOR YOUR SAFETY AND PUMP RELIABILITY
• Square shape

• Wall mount included
• Flow Rate: Approximately 3.5 ounces per minute
• Inlet Vacuum: 20+ in Hg
• Outlet Pressure: 20 PSI
• EPDM tubes
• Polypropylene and ABS cabinet

Features and Benefits:

• Maximum flexibility for customized dosing

• Choice of days, time (AM or PM) and dosings (in one ouce or 30 ml increments)
• Up to 24 dosing periods per 24 hours
• Capability to dose every day, or just on specific days
• Corrosion-resistant cabinet fitted to pail or wall for demanding environments
• Easy to program timer with pin lockout for security
• During normal operation, the timer runs on the same power source as the pump, simplifying system maintenance (only one set of batteries to replace)
• Internal backup battery in timer maintains program even when main power source is disconnected or inoperative

• No tools required for maintenance of pump assembly


Ideal Applications:

• Drains

• Cooling towers

• Boilers

• Pools

• Lubrication systems
